12mm Bore / 25mm Stroke MS Cylinder PRODUCT CODE - 12/25MS

Product Description

12mm Bore MS Pneumatic Single Acting Cylinders

Single acting, non magnetic pneumatic cylinder conforming to ISO 6432. End caps manufactured from anodised aluminium, stainless steel barrel. The polyurethane piston rod seal ensures, low friction and long service life. Operating pressure of 1 – 10 bar with temperature rating of -20C to 80C. ATEX upon request.

• The heads are connected to the body through rolling and this guarantees perfect tightening.
• The standard cylinders are provided with head and rod nut.
• The cushioning s are in nitrile rubber to cushion the impact of the piston.
• One or more magnetic reed switches can be added to the magnetic MSM type.
